FG16OHM16FM16/FG16XHOHM16FM16 Cable Construction
| Conductor | Stranded annealed or tinned Copper |
| Insulation | Cross-linked copolymer |
| Individual Screen (For multipairs only) | Aluminum/PET + tinned Copper drain wire |
| Overall Screen | Aluminum/PET + tinned Copper drain wire |
| Inner sheath | Special halogen-free compound |
| Armour | Galvanized steel wire+ Steel Counter spiral |
| Outer sheath | Special halogen-free compound |
FG16OHM16FM16/FG16XHOHM16FM16 Cable Application
FG16OHM16FM16/FG16XHOHM16FM16 Cable is suitable for installation in densely populated buildings and civil engineering structures.
FG16OHM16FM16/FG16XHOHM16FM16 Cable Technical Data
- Core identification code
- Pairs: black & white numbered
- Triads: black, white, red numbered
- Other colors code available on request
- Insulation resistance:
- 1000 MOhm x km
- Conductor stranding:
- Class 5 IEC 60228
- Nominal Voltage Uo/U:
- 600/1000 V
- Test voltage:
- C/C 3500 Vac x 5 minute
- Temperature range:
- during operation: -30° to +70°C
- during installation: -5° to +50°C
- Minimum Bending Radius:
- 10 x Outer Diameter
FG16OHM16FM16/FG16XHOHM16FM16 Cable Standards
- Constructive standard
- CEI 20-13
- CPR
- EU 305/11
- EN 50575
- Hydrocarbon & Oil
- CEI 20-34/0
- Halogen acid gas
- IEC 60754-1 (max 0,5%)
- IEC 61034-2
- Fire behavior
- IEC 60332-1-2
- IEC 60332-3-22
- EN 50399
FG16OHM16FM16/FG16XHOHM16FM16 Cable Feature
- Sunlight resistant
- Hydrocarbon and chemical resistant
- Fire behaviour
- Oil resistant
FG16OHM16FM16/FG16XHOHM16FM16 Cable Specification
| Cross section (mm2) | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
|---|---|---|---|
| 2x1,5 | 13,48 | 34 | 332 |
| 2x2x1,5 | 18,43 | 67 | 551 |
| 3x2x1,5 | 19,3 | 96 | 601 |
| 4x2x1,5 | 20,73 | 125 | 685 |
| 5x2x1,5 | 22,2 | 154 | 789 |
| 6x2x1,5 | 23,9 | 182 | 899 |
| 7x2x1,5 | 23,9 | 211 | 900 |
| 8x2x1,5 | 26,3 | 240 | 1075 |
| 9x2x1,5 | 28,95 | 269 | 1329 |
| 10x2x1,5 | 30,2 | 298 | 1437 |
| 11x2x1,5 | 30,24 | 326 | 1438 |
| 12x2x1,5 | 31,12 | 355 | 1515 |
| 3x1,5 | 13,9 | 48 | 362 |
| 2x3x1,5 | 19,9 | 96 | 663 |
| 3x3x1,5 | 20,9 | 139 | 736 |
| 4x3x1,5 | 22,5 | 182 | 860 |
| 5x3x1,5 | 24,31 | 226 | 991 |
| 6x3x1,5 | 26,18 | 269 | 1138 |
| 7x3x1,5 | 26,18 | 312 | 1152 |
| 8x3x1,5 | 29,65 | 355 | 1491 |
