FTG18M16FM16/FTG18OM16FM16 Cable Construction
| Conductors: | annealed red copper Cl.5 |
| Flame protection : | mica-glass tape, thickness > 0,10 mm |
| Insulation : | LSZH special cross-linked compound |
| Sheath: | LSZH special thermoplastic compound |
FTG18M16FM16/FTG18OM16FM16 Cable Application
- Suitable for fixed installation in the open air, in pipes or canals. Suitable for direct or indirect underground wiring.
- Suitable for fixed installation indoors and outdoors, even in wet environments. They can be mounted on walls and metal structures, platforms, pipes, ducts and similar systems.
- Suitable for energy transmission, electrical equipment signal and control transmission in high-risk areas (where smoke and acid emissions may endanger the safety of people and goods) to minimize the impact of fire spread.
- Suitable for emergency lighting and alarm systems, automatic fire detection, fire fighting equipment, automatic door opening systems, ventilation systems and air conditioning systems, etc.
FTG18M16FM16/FTG18OM16FM16 Cable Technical Data
| Rated voltage Uo/U: | 0,6/1 kV |
| Max voltage : | 1,2 kV |
| Testing voltage : | 4 kV |
| Max working temperature : | 90 °C |
| Short-circuit temperature : | 250 °C |
| Min. installation temperature : | 0 °C |
| Bending radius : | Ø x 14 |
| Max standard twisting (2x cable) : | ≥ 10 twist/meter |
FTG18M16FM16/FTG18OM16FM16 Cable Specification
| TYPE | ø ESTERNO MEDIO | Average weight |
|---|---|---|
| mm2 | mm | kg/km |
| 1x4 | 8 | 96 |
| 1x6 | 8.6 | 121 |
| 1x10 | 9.9 | 182 |
| 1x16 | 11 | 246 |
| 1x25 | 12.8 | 353 |
| 1x35 | 13.5 | 457 |
| 1x50 | 15.5 | 650 |
| 1x70 | 17.5 | 806 |
| 1x95 | 20.1 | 1062 |
| 1x120 | 22.6 | 1342 |
| 1x150 | 24.9 | 1690 |
| 1x185 | 27.7 | 1930 |
| 1x240 | 29.1 | 2500 |
| 2x1,5 | 12.2 | 191 |
| 3G1,5 | 12.8 | 217 |
| 4G1,5 | 13.9 | 243 |
| 5G1,5 | 15.1 | 298 |
| 7G1,5 | 14.2 | 315 |
| 10G1,5 | 17.8 | 420 |
| 12G1,5 | 18.9 | 492 |
| 16G1,5 | 21.1 | 596 |
| 2x2,5 | 13 | 224 |
| 3G2,5 | 13.9 | 264 |
| 4G2,5 | 14.9 | 310 |
| 5G2,5 | 16.3 | 370 |
| 7G2,5 | 15.8 | 412 |
| 10G2,5 | 19.9 | 560 |
| 12G2,5 | 21.2 | 650 |
| 2x4 | 14 | 274 |
| 3G4 | 15 | 327 |
| 4G4 | 16.1 | 380 |
| 5G4 | 17.6 | 477 |
| 2x6 | 15.2 | 342 |
| 3G6 | 16.1 | 412 |
| 4G6 | 17.6 | 489 |
| 5G6 | 19.3 | 612 |
| 2x10 | 17.8 | 496 |
| 3G10 | 18.9 | 614 |
| 4G10 | 20.7 | 756 |
| 5G10 | 22.8 | 935 |
| 2x16 | 20 | 673 |
| 3G16 | 21.2 | 819 |
| 4G16 | 23.4 | 1021 |
| 5G16 | 25.7 | 1267 |
| 2x25 | 23.6 | 900 |
| 3G25 | 25.1 | 1206 |
| 4G25 | 27.7 | 1481 |
| 5G25 | 31 | 1868 |
